RAPID SMART 360
HONDA WASH SYSTEMS - RAPID SMART 360 FOR CAR WASH

Rapid 360 is an advanced 360o high pressure Car Wash machine .

Rapid SMART 360o offers a car wash experience that leaves no one different.

The advanced programming of RAPID SMART 360o facilitates adaptation to individual user needs. Different wash programs can be configured, speeds can be parametrised, chemical products can be dosed, light sign codes can be set, etc.


Contact Us to know more about this product by submitting the form below

High Pressures

A number of high pressure pre-wash options with a common goal: removing stubborn dirt from the vehicle body

DIMENSIONS
Machine size 3500mm x 1200mm x 900mm
Water pump size 1250mm x 800mm x 600mm
Chemical mixing system size 800mm x 450mm x 1400mm
Rail length 6800mm ~ 500mm
Shipment weight / Volume 2.6 Ton
Mounting Dimensions (ceiling mounting length) 6600mm ~ 7500mm
Mounting Dimensions (floor mounting length) ≥7600mm
Mounting Dimensions (ceiling mounting width) ≥3600mm
Mounting Dimensions (floor mounting width) ≥3850mm
Mounting Dimensions (height) ≥3350mm
POWER
Power Requirements 415V/22Kw, 50Hz/60Hz
Air 80A
Total power 22kw
Water pump motor power 15kw/18.5Kw
Fan motor power 20.5Kw / full pressure 11000Pa / air volume 23000 cubic meters / h
Longitudinal motor power 0.37Kw stepless frequency control
Transversal motor power 0.75Kw digital drive motor
Rotary motor power 0.75Kw digital drive motor
Liquid proportioning system motor power 0.75kw
SYSTEM
Central processor Industrial PLC embedded central processor + dual-core system
Drive System Promise frequency digital drive
Detection system Smart three-dimensional monitoring system
Sensing System Ultrasound+ Absolute value of the digital encoder
Speed 360 wash 28 seconds, energy saving 60%
CONSUMPTIONS
Wash liquid consumption Depends on liquid proportioning
Polish shampoo consumption 10ml-40ml
Crystal wax coating consumption 18.5L could apply for 1000 cars
Water consumption Standard wash 94L/car, Fine wash 150L/car
Electricity consumption Standard wash 0.52 kW·h/car, Fine wash 0.99 kW·h/car
